MYIR | System-On-Modules (SOMs)

MYC-YA157C-V3

The MYC-YA157C-V3 is a compact System-on-Module (SoM) powered by the ST STM32MP157AAC3 processor. It integrates a dual-core ARM Cortex-A7 processor, a 209MHz ARM Cortex-M4 core, and comes with 512MB DDR3, 4GB eMMC Flash, and various expansion interfaces. This module is ideal for embedded systems such as industrial control, consumer electronics, and smart home devices, offering a combination of performance and low power consumption..

  • Detail
  • Special Features
  • Specification

The MYC-YA157C-V3 CPU Module offers an efficient solution for embedded applications, powered by the STM32MP157AAC3 processor, which combines dual ARM Cortex-A7 cores for general processing tasks and a Cortex-M4 core for real-time applications. This module includes 512MB DDR3 memory, 4GB eMMC flash, and 32KB EEPROM, enabling storage and efficient data handling. It supports a variety of connectivity options such as Gigabit Ethernet, USB 2.0, CAN, and serial ports, making it suitable for a wide range of industrial and consumer applications. The module is designed to run Linux 5.4.31 or Ubuntu 18.04, and includes robust software support, including kernel, driver source codes, and application demos to accelerate development.

  • Processor:

    • ST STM32MP157AAC3:

      • Dual-core ARM Cortex-A7 up to 650 MHz

      • Cortex-M4 core at 209 MHz with FPU/MPU

      • Integrated 3D GPU

  • Memory:

    • 512MB DDR3 (expandable to 1GB)

    • 4GB eMMC Flash (expandable to 64GB)

    • Alternative design with Nand Flash (supports 256MB, 512MB, 1GB options)

  • Networking & Communication:

    • 10/100/1000M Ethernet PHY

    • USB 2.0 Host and OTG

    • 2x CAN

    • RS232/RS485 serial ports

  • Peripherals & Expansion:

    • MIPI-DSI, Digital Camera Interface (DCMI), RGB Interface (up to 1366x768@60fps)

    • Multiple GPIOs, I2C, SPI

  • OS Support:

    • Linux 5.4.31

    • Ubuntu 18.04

  • Processor:

    • STM32MP157AAC3

      • Dual-core ARM Cortex-A7 @ 650 MHz

      • ARM Cortex-M4 @ 209 MHz

      • 3D GPU

  • Memory:

    • 512MB DDR3 (supports up to 1GB)

    • 4GB eMMC (supports up to 64GB)

    • 32KB EEPROM

  • Peripherals:

    • 10/100/1000M Ethernet PHY

    • USB 2.0 Host + OTG

    • 8x Serial ports

    • 6x I2C, 6x SPI

    • 1x MIPI-DSI, 1x DCMI

    • 1x RGB Interface (up to 1366x768 @60fps)

    • Up to 97 GPIOs

  • Power Supply:

    • 5V/0.5A

  • Temperature Range:

    • 0°C to 70°C (Commercial)

    • -40°C to +85°C (Industrial)

  • OS Support:

    • Linux 5.4.31

    • Ubuntu 18.04
